Main Frequency

120 MHz

Kernel Architecture

Single Core

IEEE754 Single-Precision Floating Point Unit (FPU)

Have

Trigonometric Function Gas Pedal（TMU）

Have

Module On Complex Mathematics（VCU-I）

-

CLA

-

CLB

Have

Instruction Storage IRAM

64kB Near End / 256kB Far End

Data Storage DRAM

Proximal 64KB

Meticulously FLASH

512KB

DMA

6ch

System Peripherals

-

32-Bit CPU Timer

3

Window Watchdog Timer

1

GPIO

43

AGPIO

16

ADC resolution (bit)

12

Number ADC Number

2

SamplingG Rate

4.6M

Number Of Channels ADC Input / Ch.

16

CMPSS

4

DAC

12bit

12bit DAC

-

PGA

-

Programmable Gain Amplifier Amplification

-

PMBus

1

I2C

2

CAN FD (CAN2.0 Compatible)

1

SPI

2

SCI (uart compatible)

2

LIN (supports switching to uart mode)

2

FSI

1

16bit/32bit EMIF

-

USB2.0

-

EtherCat

Have

EPWM Channel

7 x 14ch

HRPWM

4 x 8ch

HHRPWM

4 x 8ch

eCAP

3

HRCAP

2

eQEP

2

SDFM

-

Operating temperature range (°C)

-40℃~125℃

Package Type

LQFP 48、LQFP64、LQFP 80

Package Size / mm*mm

7X7、10X10、12X12

Typology

Low Power Consumption

Availability

-
