2000W Digital Power Solution
In digital power AC-DC conversion, the hardware topology of PFC+LLC is used. In the PFC output bus voltage is not fixed (dynamically adjusted according to the load conditions) while the LLC operating frequency range is relatively narrow (gain curve is relatively flat), the dynamic requirements of the application, the PFC and LLC common use of a QXS320F280049, CPU0 control PFC/CPU1 control LLC
Technical Parameters
| Project | Parameter Indicators | |
| Topology Of A Network (elec.) |
Topological Structure |
Single-Phase PFC + Full-Bridge LIC |
|
Input Characteristics |
Output Rated Voltage | 220VAC |
|
Input Voltage Range |
83VAC~253VAC | |
| Input Frequency Range | 47HZ~63HZ | |
| THD Value |
<5% (more than half load) |
|
| PF Value | >0.99 (more than half load) | |
| Impulse Current | <32A | |
|
Output Characteristics |
Rated Output Voltage/Current | 48VDC20A |
| Output Voltage Range | 48-72VDC | |
|
Output Current Range |
0~25A | |
| Output Current Limit Value | 26A | |
|
Output Voltage Ripple |
Ripple RMS ≤1% (full range) |
|
| Protective Function | Output Short Circuit Protection |
Yes, automatically recoverable |
| Output Overvoltage Protection |
Yes, automatically recoverable |
|
| Output Undervoltage Protection |
Yes, automatically recoverable |
|
| Output Overcurrent Protection |
Yes, automatically recoverable |
|
| Internal Overcurrent Protection |
Yes, automatically recoverable |
|
| Input Overvoltage Protection |
Yes, automatically recoverable |
|
| Input Undervoltage Protection |
Yes, automatically recoverable |
|
| Overtemperature Protection |
Yes, automatically recoverable |
|
| Environmental Indicators | Operating Temperature | -30°℃ ~+40°℃ |
| Storage Temperature | -40℃ ~+80°C | |
| Heat Dissipation Method |
Natural Cooling (external fan required for long term high temperature operation) |
|
| Sizes | 20cmx10cmx8cm | |
| Pressure Regulating/Current Regulating Method |
Potentiometer Adjustment |
|
