Main Frequency

300MHz

Kernel Architecture

Dual Core/Single CLA

IEEE754 Single-Precision Floating Point Unit (FPU)

Have

Trigonometric Function Gas Pedal（TMU）

Have

Module On Complex Mathematics（VCU-I）

Have

CLA

Have

CLB

Have

Instruction Storage IRAM

Local 768KB + Remote 1.28MB

Data Storage DRAM

Proximal 768KB

Meticulously FLASH

2MB

DMA

2×6ch

System Peripherals

-

32-Bit CPU Timer

6

Window Watchdog Timer

2

GPIO

163

AGPIO

22

ADC resolution (bit)

12、16

Number ADC Number

8

SamplingG Rate

1.19M、3.92M

Number Of Channels ADC Input / Ch.

40

CMPSS

11

DAC

12bit

12bit DAC

2

PGA

-

Programmable Gain Amplifier Amplification

-

PMBus

1

I2C

2

CAN FD (CAN2.0 Compatible)

3

SPI

4

SCI (uart compatible)

4

LIN (supports switching to uart mode)

2

FSI

2FSITX + 4FSIRX

16bit/32bit EMIF

1

USB2.0

-

EtherCat

1

EPWM Channel

18 x 36ch

HRPWM

18 x 36ch

HHRPWM

18 x 36ch

eCAP

7

HRCAP

2

eQEP

6

SDFM

16

Operating temperature range (°C)

-40℃~125℃

Package Type

HLQFP100、HLQFP176、nFBGA169、nFBGA256

Package Size / mm*mm

9X9、13X13、14X14、24X24

Typology

High Performance

Availability

-
