Main Frequency

300MHz

Kernel Architecture

Dual Core/Dual CLA

IEEE754 Single-Precision Floating Point Unit (FPU)

Have

Trigonometric Function Gas Pedal（TMU）

Have

Module On Complex Mathematics（VCU-I）

Have

CLA

2

CLB

Have

Instruction Storage IRAM

Local 768KB + Remote 1.28MB

Data Storage DRAM

Proximal 768KB

Meticulously FLASH

2MB

DMA

2×6ch

System Peripherals

-

32-Bit CPU Timer

6

Window Watchdog Timer

2

GPIO

169

AGPIO

0

ADC resolution (bit)

12、16

Number ADC Number

8

SamplingG Rate

1.1M、3.5M

Number Of Channels ADC Input / Ch.

24

CMPSS

8

DAC

12bit

12bit DAC

3

PGA

-

Programmable Gain Amplifier Amplification

-

PMBus

-

I2C

2

CAN FD (CAN2.0 Compatible)

2

SPI

3

SCI (uart compatible)

6

LIN (supports switching to uart mode)

-

FSI

-

16bit/32bit EMIF

1

USB2.0

-

EtherCat

-

EPWM Channel

18 x 36ch

HRPWM

8 x 16ch

HHRPWM

8 x 16ch

eCAP

6

HRCAP

-

eQEP

3

SDFM

8

Operating temperature range (°C)

-40℃~125℃

Package Type

HLQFP100、HLQFP176、nFBGA337

Package Size / mm*mm

14X14、16X16、24X24

Typology

High Performance
